MDS-620 Analog Oscilloscope Compact digital slow scan

Feature:

Ÿ               High luminance,internal graticule Toshiba CRT

Ÿ               The highest sampling rate is 20MS/s

Ÿ               Store depth: 1K×CH2+1K×2(Reference Memories)

Ÿ               Preset triggering function, pre-trigger signal observation

Ÿ               Two channel,two reference waveform display Simultaneous 4

Ÿ               Waveform lnformation

Ÿ               The minimum sweeping speed is 10s/DIV, The ration measures

Ÿ               the Ultra LOW Frequency Signals.

Ÿ               Measure and display Single shot, Non-period Signals

Ÿ               Built in RS232 interface for communication with the computer

Ÿ               Analog,Ultra low speed and storage oscilloscope, three in one

Ÿ               High performance with low price

Ÿ               20MHz Dual Channel

Ÿ               High Sensitivity 1mV/DIV

Ÿ               Z Axis lnput

Ÿ               CH1 Output

Ÿ               10 times sweep magnification

Ÿ               TV Synchronization, X-Y mode
